AutoCad Beginner

Educational purposes only

Commands uses:

DRAWING INITIALIZATION/SETUPS
1. Template- acdiso.dwt
2.Units- Drawing type (decimal), precision (2dec.), units (mm), others (default)
3.Precision tools and techniques - Override osnap, absolute coordinate inputs
4. Since there’s no defined position on the x and y axes, you may put it wherever you wanted .

DRAWING METHODOLOGY
1.Type “C” for circle,”0,0” , “200” for radius of the circle
2.Type “C” for circle,”0,0” , “198” for radius of the circle
3.Type “C” for circle,”0,0” , “130” for radius of the circle
4.. Type C” for circle,”0,0” , “120” for radius of the circle
5. Type “C” for circle,”0,100” , “20” for radius of the circle
6. Type “C” for circle,”0,-100” , “20” for radius of the circle
7. Type “C” for circle,”100,0” , “20” for radius of the circle
8. Type “C” for circle,”-100,0” , “20” for radius of the circle
9. Type “C” for circle,”0,100” , “10” for radius of the circle
10. Type “C” for circle,”0,-100” , “10” for radius of the circle
11. Type “C” for circle,”100,0” , “10” for radius of the circle
12. Type “C” for circle,”-100,0” , “10” for radius of the circle
13. Type “F” for Fillet,”r” , “15” , connect all 20 radius circle with the 120 radius circle, always type “F” for fillet
14. Trim the fence of 20 radius circle and 120 radius circle
15. Type “C” for circle, “0,165” , “5” for radius
16. Select the 5 radius circle to copy, “20,240” paste, “20,60” paste
17. Select “Portal Array” in the upper left corner of the tools, select the three 5 radius circle, enter, type “0,0” , enter
18. Type “20” in Items, “18” in Between , “360” fill located in the upper left corner of the tools, enter
19. Compare with the given drawing, check dimensions
20. Ctrl “s” , select location , enter file name , save

Note: Use (“”) for data/command inputs. Example: Type “L” line (command inputs), “15” (data inputs). Use ( , ) for every different data/command inputs. Example: Type “L”, enter, “100,00”, enter, .....
