Autocad - Complete tutorial for beginners (Full tutorial 1h40m)

This is a complete tutorial for beginners in Autocad.

To open this video in a Playlist (with full tutorials in Autocad):
https://youtube.com/playlist?list=PLe_I-JWckL7GGuYQuzlexzExn_E4ap_NA
--------------------------------------------------------------------------------------------------------------------------------------
Exercises to practice:
This file is free, although I am grateful I you join the CAD in Black community on Patreon. You would get access to exclusive content and we can share some ideas to help it grow in the best possible way!
Link to patreon: https://www.patreon.com/cadinblack?fan_landing=true

Video tutorial: https://youtu.be/MUgZDUdv60A
PDF file: https://drive.google.com/file/d/1JNTQu7TZNnr5c4WPZnIX0erTVI5Uz4Ip/view?usp=sharing

Notes:
25:31 - should be "anti-clockwise" instead of "clockwise"

-----

Contents:

PART 1
00:00 Introduction
01:03 Autocad display
02:47 Commands and tools
06:10 Mouse (buttons function and selecting objects)

09:43 Learn to draw lines
10:26 Draw a horizontal line
12:14 Draw a line with a specific length
13:35 Orthomode
14:06 Draw a line with an angle
15:49 Polylines
16:49 Object Snap (use precision in your drawings)
19:13 Object Snap tracking

21:10 PART 2
Other drawing commands
21:19 Rectangle
22:54 Circle
24:36 Arc

25:34 Modifying objects
25:56 Move
27:01 Copy
27:36 Rotate
29:03 Offset
31:21 Trim
34:06 Extend
36:06 Mirror
38:07 Editing objects using grips
40:27 Exercises 2

40:56 PART 3

41:24 Set up units
43:46 Layers
45:03 Create a new layer
45:46 Turn off a layer
46:18 Move an object to a different layer
46:50 Isolate layers

48:23 Blocks
49:28 Create a block
51:21 Edit a block

52:11 Print a project
52:58 Set up paper size
55:03 Change size of viewport
55:19 Set up the scale
56:10 Hide the viewport
57:08 Print with different colors

58:23 Insert text
58:37 Single line text
59:29 Multiline text

1:00:32 PART 4
1:01:21 Scale objects
1:01:38 Scale factor
1:02:44 Scale with a Reference
1:03:19 Attach an image (...and scale it)
1:06:04 Import a PDF file
1:08:44 Stretch command
1:11:07 Hatch command

1:15:12 PART 5

Array objects
1:15:16 Rectangular Array
1:18:54 Polar array
1:21:43 Path Array

1:24:58 Explode Objects
Utilities panel
1:26:28 Quick Measure
1:26:38 Distance
1:27:53 Radius
1:28:03 Angle
1:28:21 Area
1:29:18 Quick Select
1:30:09 Select all
1:30:25 Calculator

1:30:43 PART 6
Dimension Lines
1:31:25 Linear dimensions
1:31:57 Dimension Style Manager
1:33:30 Other dimension types (Aligned, Angular, Radius...)

Tips and peculiarities
1:36:20 DimLayer
1:37:36 Snaps on arrows
1:38:36 Dimension styles


Licence:
The video shows the version 2020 of AutoCAD® and it is used exclusively for educational purposes.
Autodesk screen shots reprinted courtesy of Autodesk, Inc.
The narration and all the illustrations were created by CAD in Black.
