bas ip video intercom Systems

bas IP AQ-077LL bas IP AV-03D IP Video Intercom Systems
#basip #basipvideodoorphone #basipvideointercom #basipvideodoorphone #basipindia #basipdoorsecurity #basipvideodoorbell #basip videodoorsecurity #basipindia #basipsurat #basip

Suppliers : Techfinder Electronics Pvt Ltd
Systems Integrators : Vision XP
E-mail : [email protected]
Whatsapp : wa.me/919825257770
Facebook : https://www.facebook.com/techfinder
Twitter : https://twitter.com/techfinderindia
Linkedin : https://www.linkedin.co/company/techf...
Instagram : https://www.instagram.com/techfinder.in

IP OUTDOOR PANEL AV-03D

EAN: 5060514912669 (BLACK)
EAN: 5060514912676 (TITANIUM GRAY)
BAS-IP AV-03D is a stylish entrance panel, which perfectly fits into the interior of any office center. The panel is made of high-quality plastic and applicable mainly in indoor spaces.
IP INDOOR VIDEO ENTRY PHONE AQ-07LL

EAN: 5060514914007 (BLACK)
EAN: 5060514913994 (WHITE)
The BAS-IP AQ-07LL IP video intercom indoor monitor is designed with a 7-inch stylish
TFT touch-screen colour display and plastic case. The intercom can be powered from 12V or PoE, and the classic black and white body color will suit any interior style.
bas IP AQ-077LL bas IP AV-03D IP Video Intercom Systems
BAS IP OUTDOOR PANEL AV-03D
Main features
Panel type : Individual.
Display : No.
Camera : 1/4”.
Angle: 80° horizontal x 58° vertical. Resolution : 1 Мp.
Output video : 720p (1280 × 720), H.264 Main Profile. Night backlight: 6 LEDs.
Light sensitivity : 0,01 Lux.
Protection class : IP64.
Working temperature : - 40 — +65 °С.
Power consumption : 6,5 W, in standby — 3,6 W. Power supply: PoE +12 V DC.
Body : ABS plastic.
Colors : Black, Titanium gray.
Size of the panel : 102 × 160 × 46 mm. Installation: Surface with and without a hood. Both brackets included.
Functionality
Interface : Multi-language graphical and WEB interface. Lock opening:
By means of a monitor
From the BAS-IP Intercom application From API
Access control integration: No.
Shortcut buttons: 1 touch call button.
Number of call melodies: 4 polyphonic melodies. Authentication: Separate password for settings, WEB – interface and RTSP stream.
Talking mode: Full duplex.
Additionally:
Software Link support SIP P2P
Built-in relay
Open API
IP INDOOR VIDEO ENTRY PHONE AQ-07LL
Main features
Display: 7” TFT LCD, capacitive touchscreen.
Screen resolution: 800 x 480. Built-in camera: No.
Power: PoE and + 12 V DC (PSU not included). Power consumption: 6 W,
standby 2.5 W.
Dimensions: 234 x 144.5 x 21 mm.
Colors: Black, White.
Body: Plastic.
Installation Type: Wall mount.
Possibilities of connection
Number of individual panels: Up to 9 panels. Number of multi-apartment panels: Up to 9 panels. Connection of additional monitors: Up to 8 monitors. Memory function: Record photo into internal memory (64 photo).
Interface: Multi-language graphical and
WEB interface.
Number of IP cameras: Up to 8 cameras.
Functional capabilities
Intercom type: Audio Intercom, no built-in camera. Support of receiving messages: Yes.
Select the type of screensaver in standby mode: Single IP camera live viewing.
Do Not Disturb: Yes, customizable by time. Silent mode: Yes.
Software update : From the web interface From BAS-IP updates server
