Creative Think: Making CNC Machine || 3 Axis Milling Machine || CNC Engraving Machine

#creativethink #engravingmachine #cnc #milling

i am show about making powerful cnc machine. this machine based on 3 axis. this very powerful and accuracy on this machine.

working Area= 600mm x 400mm

3d printed files:
https://bit.ly/2Rmptso

Detail,

1.16mm shaft
400mm=2pcs
600mm=4pcs
2. linear bearing (16mm)=12pcs
3.12mm shaft(200mm=2pcs)
4.linear bearing (12mm)=4pcs
5.nema 23 stepper motor= 4pcs
6. 8mm to 10mm shaft coupler=4pcs
7. Lead Screw
400mm =1PCS
600mm =2pcs
200mm =1pcs
8.palm router=1
9.2040 Aluminum Profile(400mm)=2pcs
10. 2080 Aluminum Profile(600mm)=2pcs 200mm=1pcs
11. Lead screw nut (10mm)=4pcs
12. bearing (10mm)=4pcs
-------------------------------------------------------------------------------------------------------------

Components Link :

1. 2040 Aluminum Profile
https://amzn.to/3ubzIh0

2. 2080 Aluminum Profile
https://bit.ly/2Rax50u

3. shaft (16MM)
https://amzn.to/3o8Qcoe

4. LINEAR BEARING (16mm)
https://amzn.to/3vZYkK7

5. Bolt Nut (m5)
https://amzn.to/3gTSMNk

6. Palm Router
https://amzn.to/3eJCJyD

7. Leadscrew (10mm)
https://amzn.to/3xFj6jR

8. Stepper Motor And Driver
https://amzn.to/3364pbC

9. shaft Couple (8mm to 10mm)
https://amzn.to/3t8kXKS

10. Bearing (10mm)
https://amzn.to/3eJeWio

11. Shaft (12MM)
https://amzn.to/3nEwujR

12. linear Bearing (12mm)
https://amzn.to/3vtdur2

13. cnc shield
https://amzn.to/3gUq274

14. SMPS(24V, 10A)
https://amzn.to/3vyYCHT

15. Palm Router
https://amzn.to/3eJCJyD


-------------------------------------------------------------------------------------------------------------
