FrameDesign 2D Android

For webversion of this Android app please refer to https://chrome.google.com/webstore/detail/framedesign/aegigaooooojhbfkdehjoamdmegmhlmb?utm_source=chrome-ntp-icon

This 2D linear static analysis app allows you to analyze the force distribution, deflections and tensions in 2D structures.

It is a feature rich app based on the Finite Element Method. It is especially useful for civil engineers, mechanical engineers, architects and students.

You may input and edit beams, forces, supports etc both graphically and textually. The calculations are performed transparently in the background without disturbing your work.

Main features are:
* Moment, Shear, Stress, Deflection, Reaction forces and Unity checks
*F, T and q (rectangular and triangular) loads
*Fixed and hinge connections at beam ends
*M, N, V, ux, uz, utot, phi, sigma and unity checks output
*Fixed, hinge and roller supports in any direction
*Load cases and load combinations, including safety factors
*Profile groups; each group can have its own color

*Import any steel profile or general section from our free Dako Engineering Libraries (EU, UK, AU, US & CA profiles)
*Export to our Concrete Design and Steel Design apps
*Export to picture or Word .doc document

*Undo function
*Multi copy
*Scale entire structure
*Automatic dimension lines (Autocad look)
*Element and node numbers
*Both graphical and textual edit modes
*Metric & Imperial units
*Multitouch zoom (pinch zooming)
*Many options for showing/hiding items
*Options to set almost all colors in the app
*Available in 10 Languages

*Ability to save your structures in the cloud
