AutoCAD Electrical Tutorial 1.1: Introduction to Basic WorkFlow

Subscribe and Follow my YouTube Channel for more ineresting videos.

Course Overview:
AutoCAD Electrical 2021 Comprehensive Video course is designed to give a clear understanding of AutoCAD Electrical features, capabilities and the sound knowledge of the software to enable the students to exploit the surplus availability of specially developed electrical drafting tools to enhance the productivity.
The whole course is divided into different sections to explore the interface and the process of creating precise and measured electrical drawings and schematics. In this course, you’ll learn the easiest, fastest and multiple ways to wire components together, work with Ladders and circuits, use PLC symbols, create and edit reports and create your own symbols. You will also learn many new features, tips and tricks related to simple AutoCAD and AutoCAD electrical drawings.

This course will help the students master their concepts and capabilities as listed below:

Navigate the AutoCAD Electrical interface.
Project template settings
Relationship between CAD and CADE drawings.
Multiple drawings in single project and inter-drawings relationship.
Inserting single/multiple wires/components.
Editing wires and components.
Inserting, editing and numbering wires.
Using single or 3-phase ladders and components.
Wires and components cross-referencing.
Real time error checking
Creating and editing schematic and panel BOM reports.
Creating custom symbols using symbol Builder Tool.
Setting up title block.
Creating and annotating Panel layout drawings.
Working on PLC modules.
