Linear Hall sensor

Linear Hall sensorHall sensors are widely used in various fields of modern industry, such as mechanical engineering, automotive electronics, and aviation.In contrast to mechanical and optical systems, Hall sensors have an important advantage: they are insensitive to mechanical shocks and changes in environmental parameters. At the same time they provide minimization of turnkey solution costs.The so called key Hall sensors are most widely used. Output of these sensors changes its logic state when the magnetic field strength exceeds a certain value. However there is a separate class of integrated microcircuits with the Hall element, which provide for significant expansion of the application range. This is the so called linear Hall sensors.Application of linear Hall sensors divides in two most common areas. These are devices to measure linear or angular movement and to measure electrical current. In most cases linear Hall sensors with permanent magnets are used to measure movements of objects. This is due to the fact that to maintain maximum linearity it is necessary to provide high value of change in magnetic field when changing distance between sensor and reference point on a moving object.Linear dependence and isolation from the measured current make of linear current sensor an ideal circuit for engine control. Output of the integrated circuit in Hall sensor is proportional to current in conductor; the output linear signal exactly reproduces form of the measured current.It should be noted that linear current sensor determines magnetic field value generated by currents flowing by, but not the current itself. Form of the voltage at Hall sensor output corresponds to measured current's form.Design provides sensor isolation and guarantees normal operation at high current or high voltage. In addition, it must be remembered that current sensors ought to be used in the range of values that are close to maximum because this reduces noise impact.
