ASUS A8N-E Mainboard

ASUS A8N-E Mainboard

Overclocking
This board has advanced manual options that aid in overclocking and performance-tuning efforts.
Chipset Type
NVIDIA nForce4 Ultra
Compatible Processors
Athlon 64, Athlon 64 FX
Processor Socket
Socket 939
Max Bus Speed
1000 MHz
Max Processors Qty
1
Manufacturer
Asus

Expansion / Connectivity

Expansion Slots
1 x CPU
4 x DIMM 184-pin
1 x PCIe x16
1 x PCIe x4
2 x PCIe x1
3 x PCI
Storage Interfaces
ATA-133 -connectors: 2 x 40pin IDC - RAID 0 / RAID 1 / RAID 0+1 / JBOD
Serial ATA II -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 0+1 / JBOD
Internal Interfaces
1 x floppy
2 x audio - 4 pin MPC
Additional Connectors (Optional)
6 x USB 2.0
Power Connectors
4-pin ATX12V connector, 24-pin main power connector

Storage Controller

RAID Level
JBOD, RAID 0, RAID 0+1, RAID 1
Interface Type
Serial ATA-150

Processor

Max Supported Qty
1
Installed Qty
0

Interface Provided

Type
headphones / speakers
Interface
output
Qty
1, 4
Connector Type
mini-phone stereo 3.5 mm
Type
LAN (Gigabit Ethernet), PS/2 keyboard, microphone, parallel, PS/2 mouse, SPDIF out, TOSLINK, USB 2.0, audio line-in, audio line-out (center/subwoofer), audio line-out (rear), audio line-out (side surround)
Connector Type
mini-jack

Miscellaneous

Product Type
motherboard

Audio

Audio Codec
Realtek ALC850

Processor / Memory / Storage

Max Supported Qty
1

Networking

Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Network
Gigabit Ethernet

RAM

Max Supported Size
4 GB
Features
dual channel memory architecture

Audio Output

Type
sound card
Audio Codec
Realtek ALC850
Audio
8-channel

Video

Video Output
none

Storage Controller (2nd)

Controller Interface Type
ATA-133
RAID Level
JBOD, RAID 0, RAID 0+1, RAID 1

LAN

Network Interfaces
Gigabit Ethernet

Supported RAM

Bus Clock
400 MHz, 333 MHz, 266 MHz
Features
Dual channel memory architecture
Registered or Buffered
Unbuffered
Speed
PC3200, PC2700, PC2100
Max Size
4 GB
Technology
DDR

Header

Brand
ASUS
Product Line
ASUS
Model
A8N-E
Packaged Quantity
1
Compatibility
PC

Mainboard

Form Factor
ATX
Processor Socket
Socket 939
Compatible Processors
Athlon 64, Athlon 64 FX
Data Bus Speed
1000 MHz
Chipset Type
NVIDIA nForce4 Ultra
Supported RAM Technology
DDR SDRAM
Supported RAM Speed
266 MHz, 333 MHz, 400 MHz
Supported RAM Standard
PC2100, PC2700, PC3200
Supported RAM (Registered or Buffered)
unbuffered
Power Connectors
24-pin main power connector, 4-pin ATX12V connector

Mainboard Features

BIOS Type
Phoenix-Award
BIOS Features
ASUS EZ Flash, ASUS MyLogo2, DMI 2.0 support, SMBIOS 2.3 support, WfM 2.0 support
Hardware Features
ASUS Ai Proactive, ASUS Q-Fan, CrashFree BIOS 2

Interfaces

Storage
ATA-133 (RAID), Serial ATA II (RAID)

Expansion Slots

Total Qty
1, 2, 3, 4
Type
CPU, DIMM 184-pin, PCI, PCIe x1, PCIe x16, PCIe x4

Dimensions & Weight

Width
12 in
Depth
9.6 in

Storage Interfaces

Interface
ATA-133, Serial ATA II
Connector(s)
2 x 40pin IDC, 4 x 7pin Serial ATA
RAID (Level)
RAID 0 / RAID 1 / RAID 0+1 / JBOD

Internal Interfaces

Type
audio, floppy
Connector Type
4 pin MPC
Qty
1, 2

Features

BIOS Type
Phoenix-Award
BIOS Features
DMI 2.0 support, WfM 2.0 support, ASUS MyLogo2, SMBIOS 2.3 support, ASUS EZ Flash
Hardware Features
ASUS Q-Fan, CrashFree BIOS 2, ASUS Ai Proactive
