RIPv2 config

Hi Friends, In this video I have mentioned about RIPv2 configuration and verification commands, Hope you like this video and please share your feedback with your comments in the comment section. thanks for watching this Video.


Configuration:

Practical 1: RIPv2 configuration

Conf t
line console 0
logg syn
exec-time 0 0

R1#

inter e0/0
Description link to R2
no shut
ip address 10.4.1.2 255.255.255.252

inter e0/1
Description link to Sw-1
no shut
ip add 10.1.1.1 255.255.255.0

int lo1
ip address 10.1.2.1 255.255.255.0

int lo2
ip add 10.1.5.1 255.255.255.0

Router rip
no auto-summary
network 10.0.0.0
version 2


R2#

int e0/0
description Link to R1
ip address 10.4.1.1 255.255.255.252
no shut

inter e0/1
description link to R3
no shut
ip add 10.4.1.5 255.255.255.252


inter e0/2
description link to R4
no shut
ip add 10.4.1.9 255.255.255.252


router rip
no auto-summary
version 2
network 10.0.0.0


R3#

inter e0/1
no shu
description link to R2
ip add 10.4.1.6 255.255.255.252

inter e0/0
no shut
description link to SW-3
ip add 10.25.85.1 255.255.255.0


int lo1
ip add 10.25.86.1 255.255.255.0

int lo2
ip add 10.25.87.1 255.255.255.0

int lo3
ip add 10.25.88.1 255.255.255.0


router rip
no auto-summary
version 2
network 10.0.0.0

R4#

int e0/2
no shut
description link to R2
ip address 10.4.1.10 255.255.255.252


int e0/0
no shut
description link to SW4
ip add 10.6.18.1 255.255.255.0

int lo1
ip add 10.6.19.1 255.255.255.0

int lo2
ip add 10.6.20.1 255.255.255.0

router rip
no auto-summary
version 2
network 10.0.0.0


Verification Commands:

Show ip route
show ip route rip
show ip protocols
show ip rip database
debug ip rip
undebug all or u all
debug ip udp
