CNC machining - the full process | Hermle C400 | SolidCAM | iMachining

Just Machining - 05

In this video I will show you the full CNC machining process for the shown part.
You will see the first setup which include classic 3+2 axis work as well as 5x chamfer job.
Second Setup will be an easy setup with the same vise.

⚠️ Please do not mill / drill / cut aluminum dry! This is just for video reasons and will kill your tools and parts. ⚠️

--- Technical details ---

material - EN AW – 6082 3.2315 (AlMgSi1)
machine - Hermle C400 - https://bit.ly/3qQ3h6W
vise - Allmatic Telecentric - K - https://bit.ly/3qMVDdK
CAM - SolidCAM 2021 SP2 - https://bit.ly/36gnCZN

--- my video setup * ---

camera: https://amzn.to/2SP5ymm
SSD: https://amzn.to/3yrRj65
Macro lens: https://amzn.to/3hWAYQz

----------------------------------

The left over at the end is 0,15mm, so the part is easy to take of and the Mimatic blade will also make a nice surface

-----------------------------------

0:00 Intro
0:15 plunge mill - Hoffmann - D32-Z2 - 211811 (finishing) https://bit.ly/3hGUal1
0:35 HPC drill 6xD - Hoffmann - D9.8 - 122602 https://bit.ly/3xzpDMV
0:54 HPC drill 6xD - Hoffmann - D5.8 - 122602 https://bit.ly/3xzpDMV
1:10 HPC drill 6xD - Hoffmann - D2.6 - 122602 https://bit.ly/3xzpDMV
1:24 HPC drill 8xD - Hoffmann - D3.9 - 122808 https://bit.ly/3hD6CCl
1:41 HPC reamer - Hoffmann - D4-H7 - 164346 https://bit.ly/2SSaiYD
1:57 NC reamer - Hoffmann - D10-H7 - 164340 https://bit.ly/3qOUa6F
2:29 MTC end Mill - Hoffmann - D10-Z3 - 202244 https://bit.ly/3qO5LTm
3:05 corner rounding - Hoffmann - R2,5 - 208020 https://bit.ly/3dRsyZs
3:20 corner rounding - Hoffmann - R1,5 - 208020 https://bit.ly/3dRsyZs
3:40 MTC end Mill - Hoffmann - D5-Z3 - 202244 https://bit.ly/3qO5LTm
5:07 chamfer cutter 90° - Hoffmann - D4 - 208070 https://bit.ly/2THDgur
5:55 carbide slotting tool - Hoffmann / Mimatic - D80x1.5 - 218226 https://bit.ly/3wfTPuU
7:15 finished part


---------
