ctrlX Apps – Bosch DeviceBridge using MQTT
Purchase Bosch Rexroth products online at http://www.cmafh.com
This video shows an example:
Setup the pulling of data from a device, transforming the data with DeviceBridge and sending it out via MQTT (details below).
The App - Bosch DeviceBridge - runs on the ctrlX CORE and connects to wide variety of legacy and new industrial assets and data sources like CNC’s, PLC’s, Sensors, etc., within a single instance. DeviceBridge acquires manufacturing data, processes the same and delivers it to upstream IT Applications, like MES, in the demanded format.
More info about Bosch DeviceBridge at:
https://www.bosch-softwaretechnologie...
• Video topics
00:09 Introduction
00:14 Explanation of the example
01:14 DeviceBridge App in ctrlX CORE
01:36 MQTT communication for input device
02:03 Test the connection
02:28 Add new tags in DeviceBridge
02:58 Tag Monitoring function allows read verifying
03:21 Notable communication drivers
Allen Bradley CompactLogix™ and MicroLogix™
Beckhoff TwinCAT
Modbus communication protocols
OPC UA
MQTT
and more
03:52 Collector configuration
Business Rule allows data manipulation using Google Blockly
Dynamic End Point allows for user tag setup
06:11 Further data transformation and formatting
06:22 Converters allow use of simple expressions with input data
07:32 Data Models allow formatting of input and output data
Example, formatting with JSON
08:08 Setting up a Route from input data to output data
09:07 Create a ServiceContainer for the Route
09:50 Use Publish to run the ServiceContainer of DeviceBridge in ctrlX CORE
10:20 Use ServiceMonitoring to see all services running
10:30 Use of Node-RED to generate input data and verify output data and MQTT communication
Product documentation, go to
https://bit.ly/39Kgx64 and search for “en ctrlX”
Visit ctrlX AUTOMATION at https://bit.ly/3scRezN
The online site to
- become a member of the ctrlX AUTOMATION COMMUNITY
- explore the many Apps in the ctrlX STORE
- quickly find under How-To information (FAQs, Examples, Technotes and How-To)
- use the ctrlX Forum to post, interact and find solutions
- access the product documentation download area
- go to the ctrlX AUTOMATION in GitHub
