RF Signal Source AD9959 Signal Generator AD9854 Upgrade Quad Channel DDS Module

http://pan.baidu.com/s/1kTqT3p1 Instruction Manual

(After copying the link, open it in the webpage)

http://pan.baidu.com/s/1o6CG0YY DDS Universal PC Installation Package

A link to a copy of the set
https://drive.google.com/file/d/1xILFPZHhNcUfZJ-JaHv5qaA190lUNiVz/view?usp=sharing


AD9959 RF DDS Module





First, the module features:



1, AD9959: 4 channels, 500MSPS, up to 200M sine wave output;

2, 2 / 4 channel independent frequency, amplitude and phase are adjustable;

3, 32-bit accumulator, the frequency resolution is better than 0.12HZ;

4, 14-bit phase register, phase resolution of 0.022 degrees;

5, 10-bit amplitude register, the amplitude of 1024 is finely adjustable;

6, 2nd order, 4th order, 8th order, 16th order, ASK, PSK, FSK powerful modulation function;

7, linear frequency, amplitude and phase sweep function;

8, independent programmable DAC output current;

9, high-speed SPI communication;

10, ultra-low power consumption, 4-channel 200M Signal tone output, power consumption is only 580mW;





Second, operation and description

1. Connect 5V power supply, the system working current is within 500MA.

2. The button S2 S3 is a mobile LCD cursor plus a line feed, and the S4 S5 button is added or subtracted.

3. There are 5 SMA connectors on the AD9959 core board, 4 are signal outputs, and the other is an external clock input signal. Remark: Channels 0, 1, 2, and 3 can output different frequencies, different phases, and sine waves of different amplitudes, and are independently controlled.

4. After power-on, the module initializes an I/Q signal with a frequency of 10 MHz and a phase difference of 90°. The 25 MHz active crystal oscillator and the internal frequency multiplier 20-times operation mode have a sampling rate of 500 MSa/s.

Third, the information provided:

1. A core board with a main control board containing liquid crystal.

2, the provided interface is a serial interface, providing test code.

Fourth, the physical picture is as follows:

1, the core board physical map
