Sequential Function Chart (SFC) Programming for Beginners

▶ C'mon over to https://realpars.com where you can learn PLC programming faster and easier than you ever thought possible!

▶ You can read the full post here
https://realpars.com/sequential-function-chart

⌚Timestamps:
00:00 - Intro
00:51 - What is a sequence in SFC?
01:36 - Init step
02:02 - Step or State
02:08 - Transition
03:20 - Action and Qualifiers
04:14 - SFC example

=============================

In this video, we’ll introduce you to a PLC programming language called Sequential Function Chart, or SFC for short. We will also look at an SFC example.

The PLC programming standard IEC 61131-3 includes five programming languages:
– Ladder Diagram
– Function Block Diagram
– Instruction List
– Structured Text
– Sequential Function Chart

The SFC programming language is different compared to the four other languages. The SFC is used to program a sequence directly in the PLC.

An SFC program is composed of graphic symbols. Each graphic symbol represents one step. A step is the same as a state.

- Init step: The first graphic symbol is used for initialization. This is named the init step. This is a square that is double-lined. Inside the square is a step name. When the PLC turns on the program will go into the initialization step and stay there.

- Step or State: A Step is a single-lined square.

- Transition: Each step is connected to the next step by a connection line. And a small horizontal line is added and this is called the transition. At the transition line, there must be a condition.

- Action: An action can be added to a step if required. A line connects the Step to the Action.

- Qualifiers: Inside the action box is a qualifier:

– An N qualifier means that the variable is TRUE only when the step is active. Therefore you don’t need to set the variable to FALSE when leaving the Step action.

– When using S as a qualifier, a TRUE will be stored for the variable inside the memory. This is used to keep the variable TRUE when leaving the step.

– If you need to reset the stored variable value, you can use R as a qualifier.

=============================
