Android Debug Bridge

Android Debug Bridge (adb) is a versatile command line tool that lets you communicate with an emulator instance or connected Android-powered device. It is a client-server program that includes three components:

A client, which runs on your development machine. You can invoke a client from a shell by issuing an adb command. Other Android tools such as the ADT plugin and DDMS also create adb clients.A server, which runs as a background process on your development machine. The server manages communication between the client and the adb daemon running on an emulator or device.A daemon, which runs as a background process on each emulator or device instance.






When you start an adb client, the client first checks whether there is an adb server process already running. If there isn't, it starts the server process. When the server starts, it binds to local TCP port 5037 and listens for commands sent from adb clients—all adb clients use port 5037 to communicate with the adb server.


Enabling adb Debugging

In order to use adb with a device connected over USB, you must enable USB debugging in the device system settings, under Developer options.

On Android 4.2 and higher, the Developer options screen is hidden by default. To make it visible, go to Settings About phone and tap Build number seven times. Return to the previous screen to find Developer options at the bottom.

On some devices, the Developer options screen may be located or named differently.

Note: When you connect a device running Android 4.2.2 or higher to your computer, the system shows a dialog asking whether to accept an RSA key that allows debugging through this computer. This security mechanism protects user devices because it ensures that USB debugging and other adb commands cannot be executed unless you're able to unlock the device and acknowledge the dialog. This requires that you have adb version 1.0.31 (available with SDK Platform-tools r16.0.1 and higher) in order to debug on a device running Android 4.2.2 or higher.

For more information about connecting to a device over USB, read Using Hardware Devices.

Syntax

You can issue adb commands from a command line on your development machine or from a script. The usage is:


If there's only one emulator running or only one device connected, the adb command is sent to that device by default. If multiple emulators are running andor multiple devices are attached, you need to use the -d, -e, or -s option to specify the target device to which the command should be directed.

Commands

The table below lists all of the
