Huge cable project

1. AC 9V 1.2A Power Supply
Made for Nintendo Entertainment System & Super Nintendo Entertainment System. Features a vented casing so it runs cooler than the original Nintendo power supply and it also have the same unstabilized power output. Parts from Nintendo and Philips.

2. Skyline (Composite)
Made for Nintendo Entertainment System. Double shielded cable and gold-plated plug´s with retracting shield. Improves picture quality , reduce interference and ghosting.

3. Skyline S (Prototype)
Same as Skyline (Composite) expets it uses "normal" RCA plugs.

4. Skyline (Turbo Grafx 16)
Made for NEC Turbo Grafx 16. Double shielded cable, gold-plated composite plug with retracting shield and headphone jack. Improves picture quality , reduce interference and ghosting.

5. Mono RCA
Audio cable. Double shielded.

6. Skyline (RF)
Made for Nintendo Entertainment System. This RF cable is a direct replacement and is better than the original NES RF cable. Improves picture quality on Old tube TVs. Reduce interference and ghosting. It has also been tested on Mega drive & Master system and works perfect.

7. Skyline S (Prototype)
Same as Skyline (RF) expets it uses a "normal" RCA plug.

8. Beast (Composite)
Double shielded, improves picture quality , reduce interference and ghosting.
(White prototype)

9. Beast (RF)
This RF cable is a direct replacement and is better than the original RF cable. Improves picture quality on Old tube TVs. Reduce interference and ghosting.

10. Angel (RF)
Made for Atari 2600 & Sega Megadrive rental units. This RF cable is a direct replacement and is better than the original RF cable that comes whit the system. Improves picture quality and reduce interference.

11. Angel (Composite)
Double shielded, improves picture quality , reduce interference and ghosting.

12. Nintendo RF (test) box
This is a Original Nintendo RF switch box that have been modified to quick test different coaxial cables if they are suited to be RF cables.

13. Nintendo AV / Scart (Replica)
This cable is made from Original Nintendo parts (except the scart connector) this cable actually exist and was sold by Nintendo (However it is pretty rare) This cable however also feature (Mono/mono)

14. Nintendo Y-link (Replica)
This cable was NOT sold by Nintendo. This is a replica how it might have looked if it was produced.

15. Super Nintendo Headphone Cable (Replica)
This cable was NOT sold by Nintendo. This is a replica how it might have looked if it was produced.

16. 2 x RCA - 3.5 mm female headphone
Converting RCA connectors so you can use PC Speakers.

17. 1 x RCA - 3.5 mm female headphone
Converting RCA connector in to a headphone female jack. So you can use PC Speakers. "Stereo" on the NES.

Cable prototypes that didn't make it.

All cables were built by me.

Super Nintendo RGB Scart vs. Nintendo GameCube RGB Cable
This is the 2 out of 3 official RGB scart from Nintendo. The biggest different between these 2 cables is:

Super Nintendo RGB
- Grey
- Scart - Unmarked
- Cable -- Unmarked
- No capacitor "Filter"

Nintendo GameCube RGB
- Black
- Scart - DOL-013 (EUR) CE / Nintendo
- Cable -- Black / Blue text AWM E43868 2933 VW-1SC TACH II -F-
- Capacitor "Filter"

I have been testing both cables on a Super Nintendo (PAL) & Nintendo GameCube (PAL) and even did a blind test and there was no difference in picture quality.

However I also tested both cables on a Super Famicom and they didn't work. All the colors were fudged up. It was unplayable.

If you have any questions please feel free to comment or PM me.
