EPLAN Preplanning, Version 2.7: Extensions for PCT loops

Displaying symbols in accordance with the DIN EN 62424 standard in the reports
Since Version 2.5 three special properties are available in the property dialog of the PCT loops for representation of PCT loops in the P&I diagram in accordance with the standard DIN EN 62424. On the basis of the symbols displayed additionally in the graphical editor you can recognize whether a placed measuring point or consumer is relevant to safety, or GMP- or quality-relevant.
These special properties can also be output in the reports, the labeling and the block properties for the planning objects (for example at the "Pre-planning: Planning object plan" report type in a "Data sheet PCT loops"). In order to also display the symbols in accordance with the standard DIN EN 62424 for the safety-, GMP- or quality-relevant PCT loops on the report pages, you can now use the well-known technology via the form property Assignment Property / value to graphic (ID 13026). The new symbols PCS_SQU, PCS_CIR and PCS_TRI are available in the master data of the GRAPHICS symbol library for the assignment of the graphic in the dialog of the same name.
More at: http://www.eplan.help/help/platform/2.7/en-us/help/EPLAN_help.ht #htm/news_p_preplanning_pltstellen_darstellung_126698.htm
Inserting Form Graphics
More at: http://www.eplan.help/help/platform/2.7/en-us/help/EPLAN_help.ht #htm/formeditorgui_h_formulargrafikeneinfuegen.htm
