VeeConnect Tutorial - Automatic Timing Setup

These tutorial videos will help with setting up your VeeConnect DC Power Management System.

This particular video covers setting automatic timing for a switch.

Transcript:
In this video we will show you how to set up automatic timing events in the VeeConnect system.

You can set timing on any of the switches for how many minutes and seconds the switch is on and how many minutes and seconds the switch is off. It will then do a recurring sequence until the operation is cancelled.

The way to set this up is go to the Config Menu, enter in your access PIN, the default is 7775 unless you have set up your own PIN code.

Then go into Channel Config. In this example we will use the Pump switch and set it to a 3 second on and 3 second off cycle. Select the Pump configuration screen. Slide to the bottom of the menu.

So, you can turn off or turn on the Program Cycle feature. Here we will turn it on.

Then you can select the minutes and seconds for each effect. You can use the arrow keys to change the numbers or touch the number and use the keyboard to erase and type in the numbers wanted. In this example we will set both on and off to 3 seconds.

Once done you can exit back to the main switch page.

The pump is now set for 3 seconds on and 3 seconds off and will continue that cycle until you touch the switch again the break the sequence.
