Setting up LDAP Authentication for ProxMox VE

#Proxmox #LDAP #Authentication

Full steps can be found at https://i12bretro.github.io/tutorials/0413.html

NOTE: ProxMox does not like spaces in user or group names

--------------------------------------------------------------------
Create VMAdmins Group
--------------------------------------------------------------------
   01. Click the Start button ≫ Windows Administrative Tools ≫ Active Directory Users and Computers
   02. Expand the domain name
   03. Right click on the Users container ≫ New ≫ Group
   04. Name the group VMAdmins ≫ Click OK
   05. Double click the newly created VMAdmins group
   06. Select the Members tab ≫ Click the Add... button
   07. Add users who will be administrators for the ProxMox host

--------------------------------------------------------------------
Configuring LDAP Authentication in ProxMox VE
--------------------------------------------------------------------
   01. Open a web browser and navigate to the ProxMox VE web UI
   02. Log in
   03. Select Datacenter in the left navigation menu
   04. Select Permissions ≫ Authentication in the left sub navigation menu
   05. Click the Add dropdown ≫ LDAP Server
   06. Fill out the LDAP Server form as shown below
         Realm: i12bretro.local
         Base Domain Name: CN=Users,DC=i12bretro,DC=local
         Server: 10.10.27.1
         User Attribute Name: sAMAccountName
   07. Click the Sync Options button at the top
   08. Fill out the Sync Options form as shown below
         Bind User: CN=readonly_svc,CN=Users,DC=i12bretro,DC=local
         Bind Password: Read0nly!!
         E-Mail attribute: mail
         User classes: person, user
         Group classes: group
         User Filter: (&(memberOf=CN=VMAdmins,CN=Users,DC=i12bretro,DC=local))
         Group Filter: (&(distinguishedName=CN=VMAdmins,CN=Users,DC=i12bretro,DC=local))
         Scope: Users and Groups
         Enable new users: Yes
         Full: Yes
         Purge: Yes
   09. Click the Add button
   10. Back on the Authentication page, select the new ldap authentication and click the Sync button
   11. Click the Preview button to test the sync without creating or modifying anything
   12. If the users and groups display as expected, close the preview and re-run the sync to create the users and groups
   13. Select Permissions in the left sub navigation menu
   14. Click Add ≫ Group Permission from the dropdown at the top of the page
   15. Set the path to /, select the VMAdmins group from the dropdown and select the desired Role ≫ Click Add
   16. Select the user dropdown in the top right of the screen ≫ Logout
   17. Log in with one of the LDAP users in the VMAdmins group, making sure to set the Realm to the domain realm created earlier
