OpScan® 8 Scanner

The OpScan® 8 scanner is a powerful, high performance optical mark recognition (OMR) scanner designed for high-speed data input.
Activities once requiring hours of stacking and sorting can now be managed quickly and easily. Human error and time consuming re-sorts are virtually eliminated. And, with faster, more effective form handling, turn-around time shrinks and operators are freed for more productive activities.
PHYSICAL DESCRIPTION:
• Length: 47.5” (1207 mm)
• Height: 10.5” (267 mm)
• Width: 13.25” (337 mm)
• Weight: 52 lbs (23.59 kg)
OPERATION: 2.5” x 5” to 9” x 12” (64 x 127 mm to 229 x 305 mm); 60-100 lb. (90-148 g/m2) offset; uses both Mark Reflex and Trans-Optic forms. Form Input
Capacity: Auto-feed 300 sheets. Output Stacker Capacity: 300 sheets main stacker; 100 sheets select stacker. Controls: Two push button programmable switches. Message Display: 40 character, alphanumeric, fluorescent. Scanning Rate: Model 36—3,600 sheets per hour; Model 50—5,000 sheets per hour (Actual scanning rate depends on quantity of data read from the form and the amount of processing done on that data while scanning). Programmable Interactive Transport Printer: Prints up to 63 characters per document; variable message printing based on scanned data.
