Tutorial 87: Angular Controls

How to tie horizontal and vertical controls to angle and distance controls
Workbench: http://workbench.tv/tutorials/2017-09-08_AngularControls
Patreon: http://patreon.com/workbench/
Merch: http://workbench.tv/products/merch/
Paypal: https://www.paypal.me/workbenchtv

Social
***********************************************************
Instagram: http://instagram.com/workbenchtv/
Twitter: https://twitter.com/workbench_tv
Facebook: http://facebook.com/workbenchtv

In Tutorial 85: Integrated Textures (https://www.youtube.com/watch?v=f_50Cj073ss), we made an interesting shadow out of a displaced layer. I thought it might be useful to change the default controls of Displacement Map from Max Horizontal and Max Vertical Displacement to Angle and Distance sliders. So I built that. And I continued to apply that expression to similar parameters—like position. That allowed me to animate things diagonally as easily as I can move things in X or Y. Because of that, we can put a bunch of things together going in the same direction and animate simple sliders like in our example GIF below.

Horizontal Only:
a = effect("Angle Control")("Angle");
d = effect("Distance")("Slider");
x = Math.cos(degreesToRadians(a));
x*d;

Vertical Only:
a = effect("Angle Control")("Angle");
d = effect("Distance")("Slider");
y = Math.sin(degreesToRadians(a));
y*d;

Both (for position style controls):
a = effect("Angle Control")("Angle");
d = effect("Distance")("Slider");
x = Math.cos(degreesToRadians(a));
y = Math.sin(degreesToRadians(a));
value+[x*d,y*d];
