Integrator - Operational Amplifier | Basic Circuits #14
Moving out of calculus class, the operational amplifier integrator is a great tool to have in your op-amp toolbox. As expected, the op-amp integrator takes a voltage in and integrates its behavior over time. In this tutorial, Josh reviews the concept of integration, how to put together an op-amp integrator circuit, derives the mathematical equation that describes its behavior, and finally shows a practical example of it working. Learn the basic concepts of an op-amp integrator and get a good foundational understanding of how it works in real life.
Parts of the video:
0:00 Introduction
0:16 Integration review
3:04 Integrator Circuit
3:41 How the integrator works
5:16 Integrator circuit math
10:24 Integrator circuit setup
11:45 Function generator output
12:11 Practical output with an oscilloscope
15:12 Summary
16:45 The toast will never pop up
