UT70B digital multimeter

UT70B digital multimeter UT-70B is a multifunctional digital multimeter with a large number of measurement functions and high measurement accuracy. UT-70B measures DC voltage up to 1000V, AC voltage up to 750 V, DC and AC current up to 10A, resistance up to 40 megaohms, the frequency of the alternating voltage up to 400 megahertz, capacitor's capacitance up to 40 microfarads, the temperature of -40 to 1000 degrees. In addition, you can check the diodes and test the circuit for continuity. Additional options include: display backlight, fixation of data on the display, record of the maximum and minimum values. The measurement range is selected automatically, and the units of measure are selected by switching the multi-band circular switch. At the bottom of the device there are 4 connectors for sensing wires. The delivery set includes standard sensing wires with fangs, as well as short wires with alligator clips with which it is convenient to measure the capacitance or resistance of the resistors. Also the set includes a temperature sensor for temperature measurement and RS-232 cable with the software to connect to the computer. Let's measure the voltage in the 220V network. For this let's switch on the device, set the rotary switch to voltage measurement, with the help of the selection button for DC or AC voltage select AC one and measure it; the result is seen in the display. To fix the measured data press the HOLD button. UT-70B multimeter is a multi-function instrument, which will be indispensable for measurements both at home and at work.
