ESP Prog macOS Setup Tutorial

I also have a Ko-Fi page setup, if you would like to support me here is the link:
https://ko-fi.com/mrz570177

Here are some links that I mentioned in the video:

ESP32:
https://a.co/d/fkxYMen

ESP Prog:
https://a.co/d/55VxwVZ

JTAG Interface Diagram:
https://docs.espressif.com/projects/espressif-esp-iot-solution/en/latest/hw-reference/ESP-Prog_guide.html

FT2x Driver:
https://ftdichip.com/drivers/vcp-drivers/

OpenOCD:
https://docs.espressif.com/projects/esp-idf/en/v3.3.5/api-guides/jtag-debugging/setup-openocd-macos.html

GDB:
https://sourceware.org/gdb/current/onlinedocs/gdb.html/Remote-Configuration.html
https://developer.apple.com/library/archive/documentation/DeveloperTools/gdb/gdb/gdb_18.html

VSCode:
https://code.visualstudio.com/docs/cpp/launch-json-reference
https://code.visualstudio.com/docs/editor/variables-reference

"launch": {
"version": "0.2.0",
"configurations": [
{
"type": "cppdbg",
"request": "launch",
"name": "ESP32 Debug",
"program": "${workspaceFolder}/build/${workspaceFolderBasename}.elf",
"cwd": "${workspaceFolder}/build",
"miDebuggerPath": "YOUR PATH",
"setupCommands": [{"text":"target remote 127.0.0.1:3333"},
{ "text": "set remote hardware-watchpoint-limit 2", "description": "Set only two breakpoints allowed" },
{"text": "mon reset halt","description": "Reset the chip and keep the CPUs halted"},
{"text": "flushregs","description": "Executing flushregs is a way to force GDB to get new state from the target"}
]
}
]
}
