Using Matplotlib inside ParaView Python View to plot graphs, charts, and histograms [On Demand 11]
As you know, we use ParaView a lot, and we have covered its basic concepts in the visualization series (https://www.youtube.com/playlist?list=PL6fjYEpJFi7W6ayU8zKi7G0-EZmkjtbPo), including the Python interface. But, Python integration in ParaView is not limited to the Python Interface (PvPython), and there are other tools featuring Python for people who are comfortable with using it, an example of which is Python View. Python View provides us with an easy-to-use way to plot graphics created in Python inside ParaView, and nice integration with the popular Matplotlib package allows us to create any type of Matplotlib plot out of data available in ParaView objects. We can also play with the objects using any other Python package we already know. It is very exciting, isn’t it? Let’s see how we can do that!
Video series:
Please refer to the first video of the “On Demand” series to find out more about the purpose of these videos. You can find the list of videos belonging to this series at http://tuxriders.com/videos/on-demand/ and https://www.youtube.com/playlist?list=PL6fjYEpJFi7W0gsrwHAPwRLhHlo9kyMAx
Materials:
You can find the materials developed in the videos in this repository on GitHub: https://github.com/TuxRiders/on-demand
Topics covered:
? Python View viewport in ParaView
? Writing Python scripts to be converted to ParaView plots
? How Python View deals with client-server rendering
? Using Matplotlib inside Python View
? Debugging Python View scripts
? Using Numpy features to perform interpolation in ParaView
Lecturer: Mojtaba Barzegari https://mbarzegary.github.io/
To learn more about the goals of the TuxRiders project, please visit our website at http://tuxriders.com.
Chapters in this video!
################
00:00 - Intro
01:46 - Having a first look at Python View
02:45 - How Python View works
05:14 - A sample Matplotlib graph using Python View
09:21 - A more complex Matplotlib graph using subplots
16:13 - Having more fun with the Python script: adding interpolation
