How to Add Primary Key and Foreign key in SQL Table by SQL Script

In this video I have shown how to add a Primary Key and foreign key relation in SQL Server table field by SQL Script

For this case we can set it by creating Primary key and foreign constraint by which every data will have a relation to other related table data through the Constraint and will show an error if any extra data tried to insert.
Which table contain only primary key is called parent table and another table is called child table which consist of Primary key and foreign key reference.

Foreign key increase the integrity and reduce the complexity.

These process can be done by two ways: by design view and SQL script.

Here is the Syntax of SQL Script:
SYNTAX:
Parent table :
CREATE TABLE TableName01
(
FieldnameABCD datatype PRIMARY KEY NOT NULL,
- - - - - - -
Fieldname nth datatype,
)

CREATE TABLE TableName02
(
Fieldname01 datatype PRIMARY KEY NOT NULL,
- - - - - - -
Fieldname nth datatype,
FieldnameABCD FOREIGN KEY REFERNCES TableName01 (FieldnameABCD)
)

DESIGN VIEW:
Process Steps:
1. Create Two table with primary key
2. Right Mouse Click on Child table – Relations – Add
3. Click on – Table and Column Specific -- Select Primary Key Table and field and on right side select foreign key table corresponding field – OK – Close
4. Then Save the table Again with changes.



To delete the unique constraint: Expand Table from Object explorer - - Select Created Constraint under Key Tab – Right mouse -- Delete
