Programming a Ford key fob for push button systems

This video was made for a 2017 ford fusion. However the process works with any of the intelligent keys where you use the push button start system for the 2017 and up Ford models. Below is a step-by-step process for how to program Additional key fobs. You can read the instructions or watch the video.

1. You must first have two programed keys and all of the keys have to be in the vehicle.

2. Remove the top portion of the keychain so just the remote is able to sit inside the pocket.

3. Locate the pocket in your vehicle, refer to your owners manual for the location. They are usually found in the center console of the vehicles.

4. Insert your first programed key fob into the pocket. Press the start button wait five seconds. Press the start stop button. Remove the key from the pocket.

5. Insert your second programed key fob into the pocket. Press the start button wait five seconds. Press the start stop button. Remove the key from the pocket.

6. Place the unprogrammed key into the pocket. Press and hold the start button until the horn chirps and the hazard lights flash.

7. Place your foot on the brake and start the vehicle by pushing the start stop button. A message should display on the screen that says key program successful. If not it will say key program unsuccessful and you will need to repeat the process.

I did this video Because of many poor videos and bad information that I found when trying to program these myself. I hope you found it helpful and thank you very much.
