CNC FACTORY PYTHON XPR CNC FLAT TABLE MACHINE (W/LOADING, UNLOADING)
https://www.exfactory.com/Detail/FT-010837

Specifications:
4' x 8' Flat Table "Bridge Gantry" machine with "Phenolic "MATRIX" grooved flat table for "NESTED BASE MANUFACTURING"
Working capacity:
"X" Axis 97" (2,464 mm), "Y" axis 49" (1,245 mm), "Z" axis stroke is 20.2" (515 mm), max. material thickness 10" (250 mm).
Positioning Speed:
"X" & "Y" Axis 279 FPM (85 MPM), "Z" axis 115 FPM (35 MPM);

All axes movement is with 5G Driverless servo system with direct helical rack and pinion & 5G no homing calibration;
Work Area:
Flat table design with "Matrix" grid phenolic surface for "Nested Base Manufacturing",

The machine has (4) independent working zones with dual layer high flow vacuum, 2-left origins, 2-right origins, 1-front origin & 1-rear origin.

Auto-material alignment pins, auto-unloading arm, material loading wheels; Rear and side material alignment pushers.

Automatic on/off vacuum flow, vacuum hold down communication, automatic parts hold down and release.

Robotic Material Sensing Dust Hood; Single and dual vacuum ports.
Boring Unit:
2 HP (1.5 KW) 7,000 RPM motor with (9) Independent Vertical Spindles, on 32 mm centers.
Machining:
(1) 12 HP (8.9 kW) Air cooled "HSD Electro-Spindle" with ISO 30 adaptor, RH & LH rotation; variable speed from 1,000 - 24,000 RPM.

(1) Rapid Fire 12-Position Revolving tool changer for "on the fly "ATC".
Operator & Machine Control:
"SYNTEC" PC Front End with: CNC factory 5G, 5th generation CNC control + At machine cabinet and cutting software.

Hand-held MPG remote control with individual axis and real time simulation control, CNC speed control overrides & compensation, at machine virtual support, HD digital monitoring camera, Wi-Fi and ethernet ready

Air-Conditioned control cabinet, 21" "TOUCH SCREEN" monitor; All mounted on a mobile cart;
Complete with:
(2) 12 HP, 300 m³/Hr (60Hz) vacuum pump; Automatic Pressurized lubrication system for linear guides, pads and re-circulating ball screw.

Loading conveyor table with automatic material sensing. Automatic hydraulic lifting table with both manual & auto mode

Auto-material alignment pins, auto-unloading arm, material loading wheels' Robotic Material Sensing Dust Hood.

Automatic on/off vacuum flow, vacuum hold-down communication, automatic parts hold-down and release.

Motorized outfeed conveyor belt. Single and dual vacuum ports. Space-saving integrated robotic wiring.

Rear and side material alignment pushers; Auto tool length measurement probe.

Perimeter Safety System & fencing.
Options Include:
On board Label Printer, that is Robotic application ready (robotic applicator not included).
Actual Model is CNC FACTORY PYTHON XPR CNC
