OSM Leipzig Fly-Around

Know your city. This is a 360 degree fly around over the inner city of Leipzig based on current (September 2013) OSM data.

You can produce this yourself, maybe using another location - you need:
* a WebGL enabled browser, Firefox used to produce this clip here
* ffmpeg / avconv or another (automatable) screen capturing software

In a console window do:
[3a]

Switch to the browser window:
* preload your location and zoom to the spot you want to rotate around

Open Javascript window (Shift+F4 in Firefox):
* modify the following script, adjust theta (the tilting angle) with the value used for the view you have opened, you can read theta from the adress bar
* the decrement 0.2 of a will take 1800 steps (5*360), i.e. frames, until you are at the start position again
* the interval determines how much time you give the browser to render the current view and how much time ffmpeg will get to take the snapshot of the window
[1]
* in the Javascript window, select the lines and run them (press Ctrl+R)
* wait for the job to finish, this can take a while

You will get a lot of png images, we captured three for each second, but the browser view only changed once in three seconds. Cherry pick the frames you want - I took the last of each triple, the first two were thrown away using a bash loop, something along:
[2]

Finally convert the series of png into a movie container and set the frame rate (here 20 is used, hence the playtime will be (5 * 360) / 20 = 5 * 18 = 90 seconds):
[3b]


http://pastebin.com/pbpJSi1V for [3a] [2] [3b]
http://pastebin.com/jZN47ayw for [1]


Credits go to the numerous people in history and time who have made this possible.
Credits for Data goes to (c) OpenStreetMap contributors.
Credits for WebGL goes to the Khronos Group.
Credits of the F4 WebGL-enabled Website:
Digital ElevationData
World Weather Online
node.js
Nominatim
Tilemill
PostgreSQL
PostGIS
Mapnik
Varnish
jQuery
OpenLayers
