Mastercam TRANSFORM Tab || Mirror, Roll, Rectangular array, Distribute, Stretch, Scale, Offset

Mastercam in this video we show u about Transform tab


Offset Command :-https://youtu.be/wYjSNQHLinQ

#Mirror

Use this function to create mirror images of geometric and drafting entities by reflecting them symmetrically with respect to a defined axis or point, including:

Horizontal (X) axis of the current construction plane
Vertical (Y) axis of the current construction plane
Specified angle
Selected line
Theoretical line defined between two points

#Roll

Use this function to wrap chained curves (lines, arcs, and splines) about an axis as though around a cylinder, or unwrap rolled entities to make them lie flat. The rotation axis is relative to the current construction plane. To roll or unroll entities, Mastercam breaks the entities relative to the Angle Tolerance. It then generates new geometry consisting of a line based on the break points.

#Rectangular Array

Use this function to quickly create an array (grid) of entities by copying selected entities simultaneously in two directions—Direction 1 (X) and Direction 2 (Y)—relative to the construction plane. For each direction, you specify the number of copies to create, and the offset distance and angle.



#Distribute

Use this function to create multiple copies of geometry between two defined points. Distribute places the transformed geometry between the points along a vector. It automatically arranges the copies according to the parameters that you set in the function panel. You don't have to know the distance between the points, and you can edit your results before accepting.

#Scale

Use this function to increase or decrease the size of entities by a factor relative to a defined point. You can scale all geometric and drafting entity types using either a uniform or XYZ scale method. When scaling entities, you can move, copy or join them.

OpenScaling rules

Arcs that are scaled using the XYZ scale method become splines.


#Stretch

Use this function to move (translate) entities or one or more copies of the entities to new positions and optionally lengthen or shorten selected lines. Lines are stretched when they cross or intersect the window used to select the entities. The line endpoints that lie within the selection window are translated, while the endpoints that lie outside the selection window maintain their original positions. You can select all geometric and drafting entities within the Stretch function.

You can enter values into the function panel, or use the Polar and Delta on-screen control to dynamically stretch the selected geometry.
