Introduction to FreeCAD Python API. Automate the creation of parts from a CSV (or database) - In this video I use Pandas to read a CSV and send the values as variables into FreeCAD.

The FreeCAD code is programmed mainly in C++, but relies heavily on Python
The FreeCAD source code is fully multi-platform

FreeCAD can be compiled and run without its Graphical User Interface, the code in App is independent of any GUI-related library

-solid core functionality is programmed in C++ and end-user tools are written in Python
-To get started we will look at creating parts from a CSV, without using the GUI
-This could be useful for 3d printing, eg export files as .stl

Example of what can be made with FreeCAD :
? https://forum.freecadweb.org/viewtopic.php?f=24&t=59466

FreeCAD API official documentation
? https://wiki.freecadweb.org/FreeCAD_API

TL;DW
conda install PyQt
? https://anaconda.org/anaconda/pyqt

Install FreeCAD:
? https://forum.freecadweb.org/viewtopic.php?f=4&t=56744
? https://anaconda.org/freecad/freecad

git clone https://github.com/FreeCAD/FreeCAD.git freecad-source
(get the dependencies using your method of choice)
mkdir freecad-build
cd freecad-build
cmake ../freecad-source
make
sudo make install

or

sudo add-apt-repository -y ppa:freecad-maintainers/freecad-stable
sudo apt-get update
sudo apt-get install freecad

Download Macro:
? https://wiki.freecadweb.org/Macro_Pyramid

Run from command line - no GUI!

-------------------------------------------------------------
# Example Code: file is called fc.py
#+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
#|r|e|d|a|n|d|g|r|e|e|n|.|c|o|.|u|k|
#+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+

import FreeCAD as App
#from PySide import QtGui

import pandas as pd

df = pd.read_csv("c.csv") # (read from SQL eventually)

j = len(df)

for i in range(0,j):

fn =(df.iloc[i]['name'])
lw =(df.iloc[i]['width'])
lh =(df.iloc[i]['height'])


# Make new document for each part - per line of CSV
doc = App.newDocument()
doc.FileName = fn + ".FCStd"

App.ActiveDocument.addObject("Part::Box","Box")
App.ActiveDocument.ActiveObject.Label = "Cube"
App.ActiveDocument.recompute()

#Gui.SendMsgToActiveView("ViewFit")

# Uses object called by internal name 'Box'
my_box = FreeCAD.ActiveDocument.getObject('Box')
my_box.Height = float(lw)
my_box.Width = float(lh)

doc.save()

-------------------------------------------------------------
Run with example data file : "c.csv"


name,height,width
a1,10,33
a2,3,44
a3,8,28
a4,14,38
-------------------------------------------------------------
From cli type:

[rag@~]$ freecadcmd fc.py

It will make 4 parts, with sizes as per your csv.
-------------------------------------------------------------
